US Core Implementation Guide
7.0.0 - STU7 United States of America flag

This page is part of the US Core (v7.0.0: STU7) based on FHIR (HL7® FHIR® Standard) R4. This is the current published version. For a full list of available versions, see the Directory of published versions. Page versions: STU6.1 STU6 STU5

USCDI

Page standards status: Informative

The US Core Profiles were initially designed to meet the 2015 Edition certification criterion for Patient Selection 170.315(g)(7) and Application Access – Data Category Request 170.315(g)(8). US Core Editors have updated the guide annually to meet subsequent U.S. Core Data for Interoperability (USCDI) requirements. ONC’s USCDI and FHIR US Core are complementary initiatives, with USCDI defining high-level data requirements and FHIR US Core providing detailed FHIR-based profiles for meeting those requirements. Mapping between them is necessary for achieving interoperability and consistency in healthcare data exchange within the United States. However, to make USCDI implementable in FHIR, an interpretation of USCDI is necessary. For information about what US Core Profile elements and US Core transactions are in scope for ONC Health IT Certification, see the US Core Conformance pages.

Note that:

  • USCDI Data Classes and Element names may differ from the FHIR US Core resource names and element names.
  • Not every USCDI Data Class and Element is mapped to a single profile.
  • Many US Core Profile elements do not map to a USCDI Data Classes and Element because US Core’s usage is broader than certification and because additional US Core elements are required to make FHIR implementable.

Updates to US Core depend upon community input, and we encourage our audience to submit questions and feedback to US Core specifications by clicking on the Propose a change link in the footer of every page. In addition, we encourage our audience to request any necessary clarifications to USCDI through the USCDI ONDEC process that will help inform future updates to FHIR US Core.

The table below defines the relationship between the USCDI Data Classes and Elements and USCore profiles. It lists the US Core Profile used for the corresponding Data Classes and Elements. This information and FHIRPath expressions to USCDI Data Classes and Elements are available as a csv or excel file:

USCDI Logo

US Core Data for Interoperability USCDI

Allergies and Intolerances
Allergies and Intolerances US Core AllergyIntolerance Profile
    •Substance (Medication) US Core AllergyIntolerance Profile
    •Substance (Drug Class) US Core AllergyIntolerance Profile
    •Substance (Non-Medication) US Core AllergyIntolerance Profile
    •Reaction US Core AllergyIntolerance Profile
Encounter
Encounter US Core Encounter Profile
    •Identifier US Core Encounter Profile
    •Type US Core Encounter Profile
    •Diagnosis US Core Condition Encounter Diagnosis Profile
    •Time US Core Encounter Profile
    •Location US Core Encounter Profile
    •Disposition US Core Encounter Profile
Goals and Preferences
Goals and Preferences US Core Goal Profile
    •Patient Goals US Core Goal Profile
    •SDOH Goals US Core Goal Profile See Screening and Assessments Guidance
    •Treatment Intervention Preference US Core Treatment Intervention Preference Profile
    •Care Experience Preference US Core Care Experience Preference Profile
Health Insurance Information
Health Insurance Information US Core Coverage Profile
US Core Organization Profile
    •Coverage Status US Core Coverage Profile
    •Coverage Type US Core Coverage Profile
    •Relationship to Subscriber US Core Coverage Profile
    •Member Identifier US Core Coverage Profile
    •Subscriber Identifier US Core Coverage Profile
    •Group Number US Core Coverage Profile
    •Payer Identifier US Core Coverage Profile
US Core Organization Profile
Health Status Assessments
Health Status Assessments US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
    •Health Concerns US Core Condition Problems and Health Concerns Profile
    •Functional Status US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Disability Status US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Mental/Cognitive Status US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Pregnancy Status US Core Observation Pregnancy Status Profile
US Core Observation Pregnancy Intent Profile
    •Alcohol Use US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Substance Use US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Physical Activity US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •SDOH Assessment US Core Simple Observation Profile
US Core Condition Problems and Health Concerns Profile
US Core Observation Screening Assessment Profile
US Core QuestionnaireResponse Profile
See Screening and Assessments Guidance
    •Smoking Status US Core Smoking Status Observation Profile
Medical Devices
Medical Devices US Core Implantable Device Profile
    •Unique Device Identifier(s) for a Patient's Implantable Device(s) US Core Implantable Device Profile
Patient Demographics
Patient Demographics US Core Patient Profile
US Core Observation Sexual Orientation Profile
US Core Observation Sexual Orientation Profile
US Core Observation Sexual Orientation Profile
US Core Observation Occupation Profile
    •First Name US Core Patient Profile
    •Last Name US Core Patient Profile
    •Previous Name US Core Patient Profile
    •Middle Name (including middle initial) US Core Patient Profile
    •Suffix US Core Patient Profile
    •Sex US Core Patient Profile
US Core Sex Extension
    •Date of Birth US Core Patient Profile
    •Date of Death US Core Patient Profile
    •Race US Core Race Extension
    •Ethnicity US Core Patient Profile
US Core Ethnicity Extension
    •Tribal Affiliation US Core Patient Profile
US Core Tribal Affiliation Extension
    •Gender Identity US Core Patient Profile
US Core Gender Identity Extension
    •Sexual Orientation US Core Observation Sexual Orientation Profile
    •Preferred Language US Core Patient Profile
    •Address US Core Patient Profile
    •Previous Address US Core Patient Profile
    •Email US Core Patient Profile
    •Phone Number US Core Patient Profile
    •Related Person's Name US Core RelatedPerson Profile
    •Related Person's Relationship US Core RelatedPerson Profile
    •Occupation US Core Observation Occupation Profile
    •Occupation Industry US Core Observation Occupation Profile
Patient Summary and Plan
Patient Summary and Plan US Core CarePlan Profile
    •Assessment and Plan of Treatment US Core CarePlan Profile
Provenance
Provenance US Core Provenance Profile See Basic Provenance Guidance
    •Author Time Stamp US Core Provenance Profile
    •Author Organization US Core Provenance Profile
Vital Signs
Vital Signs US Core Vital Signs Profile
    •Average Blood Pressure US Core Average Blood Pressure Profile
    •Diastolic blood pressure US Core Blood Pressure Profile
    •Systolic blood pressure US Core Blood Pressure Profile
    •Body height US Core Body Height Profile
    •Body weight US Core Body Weight Profile
    •Heart rate US Core Heart Rate Profile
    •Respiratory rate US Core Respiratory Rate Profile
    •Body temperature US Core Body Temperature Profile
    •Pulse oximetry US Core Pulse Oximetry Profile
    •Inhaled oxygen concentration US Core Pulse Oximetry Profile
    •BMI Percentile (2-20 years old) US Core Pediatric BMI for Age Observation Profile
    •Weight-for-length Percentile (Birth - 36 months) US Core Pediatric Weight for Height Observation Profile
    •Occipital Frontal Head Circumference Percentile (Birth - 36 months) US Core Pediatric Head Occipital Frontal Circumference Percentile Profile
